Lichtgewicht, lage dichtheid (~0,90 g/cm³)
Bestand tegen chemicaliën, corrosie en uitloging
Stabiel bij hoge en lage temperaturen (smeltpunt ~160-170°C)
Goede weerstand tegen vermoeiing – ideaal voor bewegende onderdelen zoals scharnieren
Structuur lijkt op polyethyleen, maar harder en beter hittebestendig
Makkelijk te vormen via extrusie, spuitgieten, etc.

Property	Test method	Unit	Guideline value
General properties
Density	ISO 1183	g/cm³	0.91
Water absorption (23°C/50% RH)	-	%	<0.2
Flammability	DIN 4102	-	B2
Specific heat capacity	-	kJ/kg·°C	2
Mechanical properties
Tensile strength	DIN 53455	N/mm²	30
Elongation at break	DIN 53455	%	>70
Elastic modulus	DIN 53457 (23°C)	N/mm²	1150
Flexural strength	DIN 53452	N/mm²	28
Impact strength (Charpy)	DIN 53453 (23°C)	-	7
Shore hardness	-	Shore D	70
Coefficient of friction	-	-	0.3
Electrical properties
Relative permittivity (100Hz)	DIN 53485	-	2.1
Dielectric loss factor (100Hz)	DIN 53483	tan (×10⁻³)	0.0003
Volume resistivity	DIN 53482	Ω·cm (10¹⁶)	>10
Surface resistivity	DIN 53482	Ω (10¹³)	>10
Comparative tracking index	DIN 53480	KC	>600
Dielectric strength	DIN 53481	kV/mm	58
Thermal properties
Crystalline melting point	-	°C	160–165
Thermal conductivity	DIN 52162	W/m·K	0.22
Linear thermal expansion coefficient	DIN 53762	mm/m·°C	0.16
Service temperature (long-term, unloaded)	-	°C	0 to 100
Max. service temperature (short-term)	-	°C	140
Heat deflection temperature	DIN 53461	°C	65
Temperature range
Minimum temperature	-	°C	0
Maximum temperature	-	°C	+100
