ABS

Name: CNCLab
Address: Nederland
Telephone: +31

Property	Test method	Unit	Guideline value
General properties
Density	ISO 1183	g/cm³	1.04
Water absorption (23°C/50% RH)	-	%	0.4
Flammability	DIN 4102	-	B2
Specific heat capacity	-	kJ/kg·°C	1.3
Mechanical properties
Tensile strength	DIN 53455	N/mm²	41
Elongation at break	DIN 53455	%	45
Elastic modulus	DIN 53457 (23°C)	N/mm²	2100
Flexural strength	DIN 53452	N/mm²	70
Impact strength (Charpy)	DIN 53453 (23°C)	-	37
Shore hardness	-	Shore D	78
Coefficient of friction	-	-	0.6
Electrical properties
Relative permittivity (100Hz)	DIN 53485	-	2.8
Dielectric loss factor (100Hz)	DIN 53483	tan (×10⁻³)	0.016
Volume resistivity	DIN 53482	Ω·cm (10¹⁶)	10
Surface resistivity	DIN 53482	Ω (10¹³)	10
Comparative tracking index	DIN 53480	KC	>600
Dielectric strength	DIN 53481	kV/mm	20
Thermal properties
Crystalline melting point	-	°C	130
Thermal conductivity	DIN 52162	W/m·K	0.25
Linear thermal expansion coefficient	DIN 53762	mm/m·°C	0.1
Service temperature (long-term, unloaded)	-	°C	-50 to 75
Max. service temperature (short-term)	-	°C	90
Heat deflection temperature	DIN 53461	°C	80
Temperature range
Minimum temperature	-	°C	-40
Maximum temperature	-	°C	+75
